Derrick:
|
210 ft x 80 ft x 60 ft; 1,250 st main & 1,000 st aux
|
|
Drawworks:
|
2 x NOV Active Heave Drawwork, 2,500 kips single speed gear driven by 6 x 1,150 HP AC motors with 2 1/8” line
|
|
Top Drive:
|
2 x NOV TDX-1250, 1250 ST hoisting, 1,200 ST rotating, torque 90,740 ft.lbs
|
|
Rotary:
|
1 x NOV RST 755 (75-1/2”) hydraulic (Main); 1 x NOV RST 605 (60-1/2”) hydraulic (Auxiliary)
|
|
Iron Roughneck:
|
Hydratong MPT TF-975 w/ TE-1190 (2 ea.); 147,000 ft-lbs.
|
|
Riser Tensioner /
Stroke:
|
(8) Dual Wireline; 225 kips with 50ft stroke
|
|
Riser Details:
|
NOV-Shaffer 21" OD, 90 ft Class H 3 1/2 M. lbs couplings & 15k 4.1/2" ID C&K lines - 10,000 ft; 54" buoyancy
|
|
BOP:
|
6 ram cavities: 2 x NOV-Shaffer NXT 18¾" 15k triple; GE-Vetco SHD H4 18¾" 15k wellhead connector
|
|
LMRP:
|
2 x NOV-Shaffer 18¾" 10k annular; GE-Vetco ExF H4 18¾"15k High Angle Release LMRP connector
|
|
Control System:
|
NOV-Shaffer 6th Gen. Multiplex Control System suitable for 12,000 ft
|
|
Pipe Handling
System:
|
2 x Hydra-Racker System HR-IV (for 3.1/2” to 20” tubulars), 2 x Hydratong MPT-200 (for 3.1/2” to 9.3/4” tool-joints)
|
|
Solids Control
|
NOV-Shaffer 6th Gen. Multiplex Control System suitable for 12,000 ft
|
|
System:
Diverter:
|
NOV-Shaffer 21 1/4" CSO for 75.1/2” Rotary table, 500 psi
|
|
Tree Storage/
|
1 x BOP trolley with skid rated 540 tons; 2 x 240 ton BOP gantry crane with dual lifting hoists, 2 x X-mas tree skids rated 120 tons, 1 x Multi-
|
|
Handling:
|
purpose cart rated 1,000 tons with 13m clearance for Xmas trees
|
|
Cranes:
|
4 x 85 MT electro-hydraulic knuckle-boom cranes at 18 m (59 ft) radius, 1 x 9 MT electro-hydraulic tubular handler at 22.3 m (73 ft) radius on forward pipe deck
|
|
Mud Pumps:
|
4 x NOV 14-P-220, 7,500 psi
|
|
Engines:
|
HIMSEN engines 6 x 8,000 KW at 720 RPM, Tier 2 compliant, each driving 1 x 7,760 kW 11kV ABB generators
|
|
Station Keeping:
|
Kongsberg DYNPOS AUTRO System for DP-3 Operations; K-POS DP32/12
|
|
Thrusters:
|
6 x Rolls Royce Aquamaster fixed pitch Azimuthing in water removable thrusters
|
